Engine Capacity (cc)
Max Power (bhp)
Manual Transmission (sp)
Engine: Ford CVH Transverse, mid mounted, rear wheel drive. Head/block al. alloy/ cast iron. 4 cylinder in line.
Bore: 80 mm.
Stroke: 79.5 mm
Capacity: 1597cc
Valve gear: sohc, 2 valves per cylinder.
Compression ratio: 9.5 to 1.
Ignition and fuel System: Electronic breakerless ignition. Bosch k-jetronic fuel injection.
Max power: 105 bhp (PS-DIN) (77kW ISO) at 6000 rpm.
Max torque: 1041lb ft (141 Nm) at 4800 rpm.
Transmission: Ford 5 speed manual Hydraulic clutch operation.
Suspension: Front - Independent, double wishbones, coil springs, telescopic dampers, anti-roll bar. Rear - Independent, MacPherson strut, lower wishbone, coil springs, telescopic dampers.
Steering: Rack and pinion with safety column and anti-theft lock.
Brakes: 2 separate circuits, split front/rear. Front 9.5 ins (240 mm) dia ventilated discs. Rear 9.7 ins (247 mm) dia discs with handbrake.
Lighting: 12 volt negative earth. Halogen headlights.
Dimension Weight: BLength 3760mm Width 1651 mm Height 1168 mm Wheelbase 2210 mm. Weight 800 Kg (1760 lbs) Fuel Tank 44 litres (10 gallons), Boot space 0.25 cubic metres.
Body: Low drag coefficient. Resin composite body with tubular steel reinforcement. Laminated screen.
Chassis: Multi-tube chassis frame constructed with heavy gauge box section steel. Tyre size 185.60x14.
Warranty: 12 months, 12,000 miles.
